S32D-W1
17 products sold in last 4 hours
Selling fast! Over 5 people have in their cart
Application
S32D series DC isolating switch is applied to 1~20KW residential or commercial photovoltaic
system, placed between photovoltage modules and inverters. Arcing time is less than 8ms,
that keeps solar system more safe. Max voltage is up to 1200V DC. It holds a safe lead among
similar products.
20 people are viewing this right now
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
Specification
| Rated current (A) | 16, 25, 32 |
|---|---|
| Standard | IEC60947-3 |
| Utilization category | DC-PV2 / DC-PV1 / DC-21B |
| Pole | 4P |
| Rated frequency | DC |
| Rated operational voltage (Ue) | 300V, 600V, 800V, 1000V, 1200V |
| Rated insulation voltage (Ui) | 1200V |
| Rated short-time withstand current (Icw) | 1kA, 1s |
| Rated impulse withstand voltage (Uimp) | 8.0kV |
| Over voltage category | II |
| Suitability for isolation | Yes |
| Polarity | No polarity (“+” and “-” polarities could be interchanged) |
| Mechanical life | 18000 times |
| Electrical life | 2000 times |
| Storage temperature | -10°C to +85°C |
| Mounting type | Vertically or horizontally |
